Wall Mount Power Supplies
| Series | Input Range |
Input Voltage |
Output Voltage |
No. Outputs |
Output Power (W) |
|
|---|---|---|---|---|---|---|
WMIIPU15 Series Description: The PSAYC series of AC/DC switching power supplies provides 2 watts of output power in a 1.33" x 0.87* x 0.67* encapsulated PCB mountable package. | Input Voltage: 90~264 | Input Voltage: 115/230 | Output Voltage: 5~5.99, 6.5~8, 8~11, 11~13, 13~16, 16~21, 21~27, 27~33, 33~40, 40~48 | No. Outputs: S | Output Power (W): 12, 13.5, 15 | Get a QuoteDownload Datasheet |
The WMIIPU15 series of AC/DC wall mount with interchangeable plugs offers up to 15 watts of output power in a 1.71” x 2.36” x 1.58” package | ||||||
WMEA1012 Series Description: The PSAYC series of AC/DC switching power supplies provides 2 watts of output power in a 1.33" x 0.87* x 0.67* encapsulated PCB mountable package. | Input Voltage: 100~240 | Input Voltage: 115/230 | Output Voltage: 5~8, 9~11, 12~17, 18~24 | No. Outputs: S | Output Power (W): 12 | Get a QuoteDownload Datasheet |
The WMEA1012 series of AC DC wall mount power supplies provides up to 12 watts of output power in a compact package. This series consists of single output models with input voltage ranging from 100-240VAC and output voltages ranging from 5V to 24V. | ||||||
WMIEM1012 Series Description: The PSAYC series of AC/DC switching power supplies provides 2 watts of output power in a 1.33" x 0.87* x 0.67* encapsulated PCB mountable package. | Input Voltage: 100~240 | Input Voltage: 115/230 | Output Voltage: 5~8V, 9~11V, 12~17V, 18~24V | No. Outputs: S | Output Power (W): 12 | Get a QuoteDownload Datasheet |
The WMIEM1012 series of AC/DC power supplies with interchangeable plugs offers up to 12 watts of output power in a 2.25” x 1.54” x 1.34” vertical package. | ||||||
WMICP30 Series Description: The PSAYC series of AC/DC switching power supplies provides 2 watts of output power in a 1.33" x 0.87* x 0.67* encapsulated PCB mountable package. | Input Voltage: 90~264 | Input Voltage: 115/230 | Output Voltage: 7.5, 9, 12, 18, 24 | No. Outputs: S | Output Power (W): 15, 18, 24, 27, 30 | Get a QuoteDownload Datasheet |
The WMICP30 series of AC DC interchangeable wall mount power supplies provides 15-30 watts of output power. This series consists of single output models with wide input voltage range of 90~264VAC and output voltages ranging from 9~24V. | ||||||
WMEA1019 Series Description: The PSAYC series of AC/DC switching power supplies provides 2 watts of output power in a 1.33" x 0.87* x 0.67* encapsulated PCB mountable package. | Input Voltage: 100~240 | Input Voltage: 115/230 | Output Voltage: 5~8, 9~13, 14~19, 20~27, 28~35, 36~48 | No. Outputs: S | Output Power (W): 15, 18, 20, 24 | Get a QuoteDownload Datasheet |
The WMEA1019 series of wall mount power supplies offers up to 20 watts of output power in a compact 2.36” x 1.54” x 1.04” package. | ||||||
WMIEA1019 Series Description: The PSAYC series of AC/DC switching power supplies provides 2 watts of output power in a 1.33" x 0.87* x 0.67* encapsulated PCB mountable package. | Input Voltage: 100~240 | Input Voltage: 115/230 | Output Voltage: 5~8, 9~13, 14~19, 20~27, 28~35, 36~48 | No. Outputs: S | Output Power (W): 15, 20 | Get a QuoteDownload Datasheet |
The WMIEA1019 series of interchangeable wall mount power supplies offers up to 20 watts of output power in a compact 2.25” x 1.33” x 1.53” package. | ||||||
WMIGMPU18 Series Description: The PSAYC series of AC/DC switching power supplies provides 2 watts of output power in a 1.33" x 0.87* x 0.67* encapsulated PCB mountable package. | Input Voltage: 100~240 | Input Voltage: 115/230 | Output Voltage: 5~6, 6~8, 8~11, 11~13, 13~16, 16~21, 21~27, 27~33, 33~58 | No. Outputs: S | Output Power (W): 15, 18.04, 18.08, 18.09, 18.15, 18.56 | Get a QuoteDownload Datasheet |
The WMIGMPU18 power supply series of AC/DC wall mount with interchangeable plugs offers 18 watts of output power in a compact package. | ||||||
WMEM1019 Series Description: The PSAYC series of AC/DC switching power supplies provides 2 watts of output power in a 1.33" x 0.87* x 0.67* encapsulated PCB mountable package. | Input Voltage: 100~240 | Input Voltage: 115/230 | Output Voltage: 5~8, 9~13, 14~19, 20~27, 28~35, 36~48 | No. Outputs: S | Output Power (W): 15, 18, 20, 24 | Get a QuoteDownload Datasheet |
The WMEM1019 series of AC/DC wall mount power supplies offers up to 24 watts of output power in a 2.36” x 1.54” x 1.02” case size. | ||||||
WMEM1024 Series Description: The PSAYC series of AC/DC switching power supplies provides 2 watts of output power in a 1.33" x 0.87* x 0.67* encapsulated PCB mountable package. | Input Voltage: 100~240 | Input Voltage: 115/230 | Output Voltage: 5~8, 9~11, 12, 12~17, 18~24, 24, 36~48 | No. Outputs: S | Output Power (W): 16, 18, 20, 24, 27, 30, 36 | Get a QuoteDownload Datasheet |
AC DC Power Supplies - The WMEM1024 series of AC to DC wall mount power supplies provides up to 36 watts of output power. Models are available in United States (US), United Kingdom (UK), Europe (EU), and Australia (AUS) types. | ||||||
WMIPEA1024 Series Description: The PSAYC series of AC/DC switching power supplies provides 2 watts of output power in a 1.33" x 0.87* x 0.67* encapsulated PCB mountable package. | Input Voltage: 100~240 | Input Voltage: 115/230 | Output Voltage: 5~8, 9~11, 12, 12~17, 18~24, 24, 36~48 | No. Outputs: S | Output Power (W): 16, 18, 20, 24, 27, 30, 36 | Get a QuoteDownload Datasheet |
The WMIPEA1024 series of AC DC power supplies provides up to 36 Watts of continuous output power in a 2.9” x 1.69” x 1.28” package. All models have a single output and a wide input voltage range of 100~240VAC. | ||||||
What are wall mount power supplies?
Wall mount power supplies are amongst the most commonly used sources of lower voltage power. They provide a simple means of supplying safe power to a wide range of devices. A wall mount power supply typically consists of a small plastic box that can plug directly into the wall. The bulk of the unit is plugged into the wall with a cable leading off to the device.
What types of wall mount power supplies are there?
Wall mount power supplies can be either AC or DC. They come in a range of configurations, depending on the scenario that they’re designed for.
Regulated – Regulated wall mount power supplies feature voltage regulators that ensure the output voltage remains consistent, never deviating from the rated value of power supply.
Unregulated – Unregulated wall mount power supplies differ in that their output voltage will decrease as the output current increases and vice versa. This means that the power supply must be matched as closely as possible to the voltage and current requirements of the device in question.
Linear – Linear wall mount power supplies convert high voltage AC into low voltage, this is then converted into DC voltage. Whilst these tend to have low efficiency, they are also more reliable and faster than switching mode power supplies.
Switching mode power supplies – Wall mount switching mode power supplies convert the input signal into DC before stepping down or up the voltage to the required level. These power supplies have high efficiency and are less bulky than their linear counterparts.
What are the primary components of a wall mount power supply?
Depending on its configuration, a wall mount power supply will typically consist of a transformer, a rectifier, smoothing, a regulator and load. The input transformer steps down the AC power, a rectifier circuit converts the AC components present into DC component. The signal is then smoothed out by a filtering circuit. A regulator controls the voltage to the desired level, before leading to the load which uses the pure DC output from the regulated output.
Where are wall mount power supplies used?
Wall mount power supplies are used in a wide range of industries and applications. They can be designed for use with a full range of input voltages and can output to a similarly wide range of wattages. Linear wall mount power supplies are typically used in audio frequency applications due to their immunity to RFI. Meanwhile, wall mount switch mode power supplies are used in phone chargers and DC motors.
How do you choose a wall mount power supply?
In order to choose the right wall mount power supply for your requirements, you need to first find out where your device needs AC or DC. You’ll usually find the power requirement on the device itself, look for the voltage requirements so that you can ensure you are providing the correct amount of power. Too much or too little power may lead to your device being damaged.
