PSRAD

The PSRAD series of AC/DC rectifiers offers up to 3000 watts of output power in a 11.06” x 4.13” x 1.61” package. This series consists of single output models with three wide operating input ranges and two system types. These models feature high efficiency, high power density, soft start, parallel operations, input under and over voltage protection, as well as over voltage, short circuit, and over voltage protection. The PSRAD series supports solar system input, voltage adjustment, current limiting, current sharing, hot swap, CAN bus communication, soft start, and it also has TUV and CE approvals. Please contact factory for ordering information.

• Wide Operating Input Ranges of 90V~430VDC (PV (Solar) Mode), 90V~420VDC (HVDC Mode), & 90V~290VAC (AC Mode) • High Efficiency • High Power Density • Full Function Digital Controls • Supports Solar System Input (integrated MPPT control) • Supports Voltage Adjustment, Current Limiting and Current Sharing • Supports Hot Swap • Supports CAN Bus Communication • Supports LED Warning Signals • Soft Start • Parallel Operations • Input Over & Under Voltage Protection • Over Voltage, Short Circuit, and Over Voltage Protection • TUV & CE Approvals
Model
Number
Input
Voltage
Output
Voltage
Output
Current
Output
Power (W)
No.
Outputs
Case
PSRAD-48S Input Voltage: 90~290 Output Voltage: 53.5 Output Current: See Data Sheet Output Power (W): 1250~2500 No. Outputs: S Case: Enclosed with Fan Get a Quote
PSRAD-60S Input Voltage: 90~290 Output Voltage: 67 Output Current: See Data Sheet Output Power (W): 1250~3000 No. Outputs: S Case: Enclosed with Fan Get a Quote
Specification Value
Input
Input Voltage (Nominal): 176/290
Input Voltage Range: 90~290
OVLO: Solar Mode Set Point: ≥435VDC
Solar Mode Recover Range: 425-434VDC
HVDC Mode Set Point: ≥430VDC
HVDC Mode Recover Range: 420-430VDC
AC Mode Set Point: 298-310VAC
AC Mode Recover Range: 290-298VAC
UVLO: Solar Mode Set Point: 83VDC Max.
Solar Mode Recover Range: 85-90VDC
HVDC Mode Set Point: ≤85VDC
HVDC Mode Recover Range: ≤90VDC
AC Mode Set Point: ≤85VAC
AC Mode Recover Range: ≤90VAC
Output
Output Voltage: 53.5, 67
Output Current: See Data Sheet
Output Power (Watts): 1250, 2500, 3000
Short Circuit Protection: Yes
Over Voltage Protection: PSRAD-48S: 56~60VDC
PSRAD-60S: 70~75.5VDC
General
Efficiency: Up to ≥96.5%
Environmental
Operating Temperature: -40 to +75ºC
Storage Temperature: -40 to +75ºC
Physical
Weight: ≤5.5lbs (2.5kg)
Dimensions: 11.06in x 4.13in x 1.61in (281mm x 105mm x 40.8mm)
Notes & safety
Notes: *Due to advances in technology, specifications subject to change without notice.
Safety Approvals: TUV, CE
TUV Efficiency Level: TUV
