WMEPU10
The WMEPU10 series of AC/DC wall mount power supplies provides 10 watts of continuous output power in a 2.20 x 1.73 x 1.08 inch package. This series consists of models with an input voltage range of 90~264VAC and single outputs ranging from 5VDC to 48VDC. All units are UL 94V-1 and RoHS compliant, and models over 5V are Energy Star Level VI compliant. This series also meets new CE requirements and FCC class B emission limits. All models have UL/cUL (UL 60950-1: 2nd edition) and TUV/GS (EN 60950-1: 2nd edition) safety approvals. All units have been 100% burn-in tested.
• Class II
• RoHS Compliant
• 10 Watts Output Power
• Single Outputs
• 85% High Efficiency
• Energy Star 2.0, Efficiency Level VI (Except models 5~11V)
• 90-264VAC Input Voltage Range
• 1 Year Warranty
• Approved as Limited Power Source (LPS)
• UL/cUL (UL 60950-1: 2nd Edition) Safety Approvals
• Meets FCC Class B Emission Limits
• 2 Prong Plug-In Mains Connector
• 100% Burn-In Tested
• Optional Output Connectors Available
• Short Circuit Protection
| Model Number |
Input Voltage |
Output Voltage |
Output Current |
Output Power (W) |
No. Outputs |
Case | Size | |
|---|---|---|---|---|---|---|---|---|
| WMEPU10-102 | Input Voltage: 90~264 | Output Voltage: 5~5.99 | Output Current: 1.33~1.60A | Output Power (W): 8 | No. Outputs: S | Case: Wall Mount | Size: 2.2" x 1.73" x 1.08" | Get a Quote |
| WMEPU10-103 | Input Voltage: 90~264 | Output Voltage: 6.5~8 | Output Current: 1.00~1.23A | Output Power (W): 8 | No. Outputs: S | Case: Wall Mount | Size: 2.2" x 1.73" x 1.08" | Get a Quote |
| WMEPU10-104 | Input Voltage: 90~264 | Output Voltage: 8~11 | Output Current: 0.90~1.25A | Output Power (W): 10 | No. Outputs: S | Case: Wall Mount | Size: 2.2" x 1.73" x 1.08" | Get a Quote |
| WMEPU10-105 | Input Voltage: 90~264 | Output Voltage: 11~13 | Output Current: 0.76~0.90A | Output Power (W): 10 | No. Outputs: S | Case: Wall Mount | Size: 2.2" x 1.73" x 1.08" | Get a Quote |
| WMEPU10-106 | Input Voltage: 90~264 | Output Voltage: 13~16 | Output Current: 0.62~0.76A | Output Power (W): 10 | No. Outputs: S | Case: Wall Mount | Size: 2.2" x 1.73" x 1.08" | Get a Quote |
| WMEPU10-107 | Input Voltage: 90~264 | Output Voltage: 16~21 | Output Current: 0.47~0.62A | Output Power (W): 10 | No. Outputs: S | Case: Wall Mount | Size: 2.2" x 1.73" x 1.08" | Get a Quote |
| WMEPU10-108 | Input Voltage: 90~264 | Output Voltage: 21~27 | Output Current: 0.37~0.47A | Output Power (W): 10 | No. Outputs: S | Case: Wall Mount | Size: 2.2" x 1.73" x 1.08" | Get a Quote |
| WMEPU10-109 | Input Voltage: 90~264 | Output Voltage: 27~33 | Output Current: 0.30~0.37A | Output Power (W): 10 | No. Outputs: S | Case: Wall Mount | Size: 2.2" x 1.73" x 1.08" | Get a Quote |
| WMEPU10-110 | Input Voltage: 90~264 | Output Voltage: 33~40 | Output Current: 0.25~0.30A | Output Power (W): 10 | No. Outputs: S | Case: Wall Mount | Size: 2.2" x 1.73" x 1.08" | Get a Quote |
| WMEPU10-111 | Input Voltage: 90~264 | Output Voltage: 40~48 | Output Current: 0.20~0.25A | Output Power (W): 10 | No. Outputs: S | Case: Wall Mount | Size: 2.2" x 1.73" x 1.08" | Get a Quote |
| Specification | Value |
|---|---|
| Input | |
| Input Voltage (Nominal): | 115/230 |
| Input Voltage Range: | 90~264 |
| Input Frequency: | 47-63Hz |
| Output | |
| Output Voltage: | 5~5.99, 6.5~8, 8~11, 11~13, 13~16, 16~21, 21~27, 27~33, 33~40, 40~48 |
| Output Current: | 1.33~1.60A, 1.00~1.23A, 0.90~1.25A, 0.76~0.90A, 0.62~0.76A, 0.47~0.62A, 0.37~0.47A, 0.30~0.37A, 0.25~0.30A, 0.20~0.25A |
| Output Power (Watts): | 8, 10 |
| Short Circuit Protection: | Automatic Recovery |
| General | |
| Efficiency: | 71-85% |
| Isolation: | 4242VDC |
| Environmental | |
| Operating Temperature: | 0 to 70°C |
| Storage Temperature: | -40 to 85°C |
| Physical | |
| Weight: | 3.17oz (90g) |
| Dimensions: | 2.20" x 1.73" x 1.08" (56.0 x 44.0 x 27.5 mm) |
| Notes & safety | |
| Notes: | 1. The output voltage is specified as a range (ex: 40~48VDC); the customer must specify what they would like the output voltage set at. Output can provide up to peak load when the power supply starts up. Staying in more than rated load continually is not allowed. Each output checked to be within voltage accuracy in 60% rated load condition. 2. Models DTEPU10A-102~105 need to use AWG#20/4FT output cable in order to meet the total regulation specified. Models DTEPU10A-106~108 need to use AWG#22/4FT output cable in order to meet the total regulation specified. Models DTEPU10A-109~111 need to use AWG#24/4FT output cable in order to meet the total regulation specified. The regulation and efficiency will change if a different output cable is used. 3. Optional output connectors are available for this series. Please call factory for ordering details. 4. Line regulation is defined by changing ±10% of input voltage from nominal line at rated load. 5. Load regulation is defined by changing ±40% of measured output load from 60% rated load 6. Ripple & Noise is measured by using 20MHz bandwidth limited oscilloscope and terminated each output with a 0.47µF capacitor at rated load and nominal line. 7. Hold up time is measured from the end of the last charging pulse to the time which the main output drops down to low limit of main output at rated load and nominal line. 8. Efficiency is measured at rated load and nominal line. 9. This product is Listed to applicable standards and requirements by UL. Due to advances in technology, specifications are subject to change without notice. |
| Safety Approvals: | UL/cUL (UL60950-1: 2nd edition), CE |
| RoHS Compliance: | Yes |
| TUV Efficiency Level: | TUV/GS (EN 60950-1: 2nd edition) |
| Energy Star Compliance: | Level V, VI |
