WMEM1005

The WMEM1005 series of AC/DC medical wall mount power supplies offers up to 6 watts of output power in a horizontal or vertical case. This series consists of single output models with an input voltage range of 100 to 240VAC. Several options are available for this series; horizontal or vertical case type, USB or Strain Relief output type, and either UK, USA, or EU plug type. Each model in this series is RoHS and CEC Level VI compliant and has over voltage, short circuit, and over current protection. This series has UL/cUL, UL60601, TUV EN60601, CB 60601, CE, and FCC safety approvals. Please call factory for order details.

• Input Voltage Range of 100 to 240VAC • USB or Strain Relief Types • Meets CEC Level VI (DoE) • RoHS Compliance • UK, USA, or EU Plug Type • Over Voltage, Short Circuit, and Over Current Protection • Vertical or Horizontal Package Available • UL/cUL, UL60601, TUV EN60601, CB 60601, CE, and FCC Safety Approvals
Model
Number
Input
Voltage
Output
Voltage
Output
Current
Output
Power (W)
No.
Outputs
Case
WMEM1005CVUx Input Voltage: 100~240 Output Voltage: 9 Output Current: 0.5A Output Power (W): 4.5 No. Outputs: S Case: Wall Mount Get a Quote
WMEM1005CVEx Input Voltage: 100~240 Output Voltage: 9 Output Current: 0.5A Output Power (W): 4.5 No. Outputs: S Case: Wall Mount Get a Quote
WMEM1005CVKx Input Voltage: 100~240 Output Voltage: 9 Output Current: 0.5A Output Power (W): 4.5 No. Outputs: S Case: Wall Mount Get a Quote
WMEM1005CHUx Input Voltage: 100~240 Output Voltage: 9 Output Current: 0.5A Output Power (W): 4.5 No. Outputs: S Case: Wall Mount Get a Quote
WMEM1005CHEx Input Voltage: 100~240 Output Voltage: 9 Output Current: 0.5A Output Power (W): 4.5 No. Outputs: S Case: Wall Mount Get a Quote
WMEM1005AVUx Input Voltage: 100~240 Output Voltage: 5~8 Output Current: 1.2A Output Power (W): 6 No. Outputs: S Case: Wall Mount Get a Quote
WMEM1005AVEx Input Voltage: 100~240 Output Voltage: 5~8 Output Current: 1.2A Output Power (W): 6 No. Outputs: S Case: Wall Mount Get a Quote
WMEM1005AVKx Input Voltage: 100~240 Output Voltage: 5~8 Output Current: 1.2A Output Power (W): 6 No. Outputs: S Case: Wall Mount Get a Quote
WMEM1005BVUx Input Voltage: 100~240 Output Voltage: 9~12 Output Current: 0.66A Output Power (W): 6 No. Outputs: S Case: Wall Mount Get a Quote
WMEM1005BVEx Input Voltage: 100~240 Output Voltage: 9~12 Output Current: 0.66A Output Power (W): 6 No. Outputs: S Case: Wall Mount Get a Quote
WMEM1005BVKx Input Voltage: 100~240 Output Voltage: 9~12 Output Current: 0.66A Output Power (W): 6 No. Outputs: S Case: Wall Mount Get a Quote
WMEM1005DVUx Input Voltage: 100~240 Output Voltage: 9 Output Current: 0.67A Output Power (W): 6 No. Outputs: S Case: Wall Mount Get a Quote
WMEM1005DVEx Input Voltage: 100~240 Output Voltage: 9 Output Current: 0.67A Output Power (W): 6 No. Outputs: S Case: Wall Mount Get a Quote
WMEM1005DVKx Input Voltage: 100~240 Output Voltage: 9 Output Current: 0.67A Output Power (W): 6 No. Outputs: S Case: Wall Mount Get a Quote
WMEM1005AHUx Input Voltage: 100~240 Output Voltage: 5~8 Output Current: 1.2A Output Power (W): 6 No. Outputs: S Case: Wall Mount Get a Quote
WMEM1005AHEx Input Voltage: 100~240 Output Voltage: 5~8 Output Current: 1.2A Output Power (W): 6 No. Outputs: S Case: Wall Mount Get a Quote
WMEM1005BHUx Input Voltage: 100~240 Output Voltage: 9~12 Output Current: 0.66A Output Power (W): 6 No. Outputs: S Case: Wall Mount Get a Quote
WMEM1005BHEx Input Voltage: 100~240 Output Voltage: 9~12 Output Current: 0.66A Output Power (W): 6 No. Outputs: S Case: Wall Mount Get a Quote
WMEM1005DHUx Input Voltage: 100~240 Output Voltage: 9 Output Current: 0.67A Output Power (W): 6 No. Outputs: S Case: Wall Mount Get a Quote
WMEM1005DHEx Input Voltage: 100~240 Output Voltage: 9 Output Current: 0.67A Output Power (W): 6 No. Outputs: S Case: Wall Mount Get a Quote
Specification Value
Input
Input Voltage (Nominal): 115/230
Input Voltage Range: 100~240
Output
Output Voltage: 5~8, 9, 9~12
Output Current: 0.67A, 0.5A, 0.66A, 1.2A
Output Power (Watts): 4.5, 6
Short Circuit Protection: Automatic Recovery
Over Voltage Protection: Automatic Recovery
General
Environmental
Operating Temperature: 0 to 40ºC
Storage Temperature: -20 to 85ºC
Physical
Weight: 2.47oz (70g)
Dimensions: Horizontal USB Output: 2.19in x 1.46in x 1.07in
Horizontal Strain Relief Output: 2.17in x 1.42in x 0.98in
Vertical USA & EU Plugs: 1.61in x 1.16in x 2.10in
Vertical UK Plug: 1.61in x 1.37in x 2.10in
Notes & safety
Notes: 1. “X” in model number indicates either a USB or Strain Relief output type. “X” is “U” for USB or “S” for Strain Relief.
2. Please note, only US and EU plugs are available for the horizontal case type.
3. Ripple & Noise is measured by using 20MHz bandwidth limited oscilloscope and terminated each output with a 0.1uF ceramic capacitor & parallel with 47uF aluminum capacitor at full load and nominal line.
4. Line regulation is defined by changing ±10% of input voltage from nominal line at rated load.
*Due to advances in technology, specifications subject to change without notice.
Safety Approvals: UL/cUL, UL60601, TUV EN60601, CB 60601, CE, FCC
RoHS Compliance: Yes
TUV Efficiency Level: TUV EN60601
Energy Star Compliance: Level VI
