PSAJM24
The PSAJM24 Series of AC/DC medical and industrial power modules offers up to 24 watts of output power in a PCB, Chassis or DIN Rail fully encapsulated plastic case. This series consists of single and dual output models with a universal input range of 85-264VAC and I/O isolation 4000VAC with reinforced insulation. Each model in this series has over load, over voltage, and short circuit protection , is RoHS & REACH compliant, and has both medical and industrial safety approvals. Please call factory for order details.
• Universal 85-264VAC Input Voltage Range
• Fully Encapsulated Plastic Case for PCB, Chassis, and DIN-Rail Versions
• I/O Isolation 4000VAC with Reinforced Insulation
• Over Load, Over Voltage, and Short Circuit Protection
• Protection Class II per IEC/EN 60536
• RoHS & REACH Compliant
• Medical and Industrial Safety Approvals
| Model Number |
Input Voltage |
Output Voltage |
Output Current |
Output Power (W) |
No. Outputs |
Case | Size | |
|---|---|---|---|---|---|---|---|---|
| PSAJM-24S05 | Input Voltage: 85~264 | Output Voltage: 5 | Output Current: 3000mA | Output Power (W): 24 | No. Outputs: S | Case: PCB Mount | Size: 2.91 x 2.13 x 0.77" | Get a Quote |
| PSAJM-24S09 | Input Voltage: 85~264 | Output Voltage: 9 | Output Current: 2666mA | Output Power (W): 24 | No. Outputs: S | Case: PCB Mount | Size: 2.91 x 2.13 x 0.77" | Get a Quote |
| PSAJM-24S12 | Input Voltage: 85~264 | Output Voltage: 12 | Output Current: 2000mA | Output Power (W): 24 | No. Outputs: S | Case: PCB Mount | Size: 2.91 x 2.13 x 0.77" | Get a Quote |
| PSAJM-24S15 | Input Voltage: 85~264 | Output Voltage: 15 | Output Current: 1600mA | Output Power (W): 24 | No. Outputs: S | Case: PCB Mount | Size: 2.91 x 2.13 x 0.77" | Get a Quote |
| PSAJM-24S24 | Input Voltage: 85~264 | Output Voltage: 24 | Output Current: 1000mA | Output Power (W): 24 | No. Outputs: S | Case: PCB Mount | Size: 2.91 x 2.13 x 0.77" | Get a Quote |
| PSAJM-24S05C | Input Voltage: 85~264 | Output Voltage: 5 | Output Current: 3000mA | Output Power (W): 24 | No. Outputs: S | Case: Chassis Mount | Size: 3.78 x 2.13 x 0.92" | Get a Quote |
| PSAJM-24S09C | Input Voltage: 85~264 | Output Voltage: 9 | Output Current: 2666mA | Output Power (W): 24 | No. Outputs: S | Case: Chassis Mount | Size: 3.78 x 2.13 x 0.92" | Get a Quote |
| PSAJM-24S12C | Input Voltage: 85~264 | Output Voltage: 12 | Output Current: 2000mA | Output Power (W): 24 | No. Outputs: S | Case: Chassis Mount | Size: 3.78 x 2.13 x 0.92" | Get a Quote |
| PSAJM-24S15C | Input Voltage: 85~264 | Output Voltage: 15 | Output Current: 1600mA | Output Power (W): 24 | No. Outputs: S | Case: Chassis Mount | Size: 3.78 x 2.13 x 0.92" | Get a Quote |
| PSAJM-24S24C | Input Voltage: 85~264 | Output Voltage: 24 | Output Current: 1000mA | Output Power (W): 24 | No. Outputs: S | Case: Chassis Mount | Size: 3.78 x 2.13 x 0.92" | Get a Quote |
| PSAJM-24S05DN | Input Voltage: 85~264 | Output Voltage: 5 | Output Current: 3000mA | Output Power (W): 24 | No. Outputs: S | Case: DIN Rail | Size: 3.78 x 2.13 x 1.35" | Get a Quote |
| PSAJM-24S09DN | Input Voltage: 85~264 | Output Voltage: 9 | Output Current: 2666mA | Output Power (W): 24 | No. Outputs: S | Case: DIN Rail | Size: 3.78 x 2.13 x 1.35" | Get a Quote |
| PSAJM-24S12DN | Input Voltage: 85~264 | Output Voltage: 12 | Output Current: 2000mA | Output Power (W): 24 | No. Outputs: S | Case: DIN Rail | Size: 3.78 x 2.13 x 1.35" | Get a Quote |
| PSAJM-24S15DN | Input Voltage: 85~264 | Output Voltage: 15 | Output Current: 1600mA | Output Power (W): 24 | No. Outputs: S | Case: DIN Rail | Size: 3.78 x 2.13 x 1.35" | Get a Quote |
| PSAJM-24S24DN | Input Voltage: 85~264 | Output Voltage: 24 | Output Current: 1000mA | Output Power (W): 24 | No. Outputs: S | Case: DIN Rail | Size: 3.78 x 2.13 x 1.35" | Get a Quote |
| PSAJM-24D12 | Input Voltage: 85~264 | Output Voltage: 12, -12 | Output Current: ±1000mA | Output Power (W): 24 | No. Outputs: D | Case: PCB Mount | Size: 2.91 x 2.13 x 0.77" | Get a Quote |
| PSAJM-24D15 | Input Voltage: 85~264 | Output Voltage: 15, -15 | Output Current: ±800mA | Output Power (W): 24 | No. Outputs: D | Case: PCB Mount | Size: 2.91 x 2.13 x 0.77" | Get a Quote |
| PSAJM-24D12C | Input Voltage: 85~264 | Output Voltage: 12, -12 | Output Current: ±1000mA | Output Power (W): 24 | No. Outputs: D | Case: Chassis Mount | Size: 3.78 x 2.13 x 0.92" | Get a Quote |
| PSAJM-24D15C | Input Voltage: 85~264 | Output Voltage: 15, -15 | Output Current: ±800mA | Output Power (W): 24 | No. Outputs: D | Case: Chassis Mount | Size: 3.78 x 2.13 x 0.92" | Get a Quote |
| PSAJM-24D12DN | Input Voltage: 85~264 | Output Voltage: 12, -12 | Output Current: ±1000mA | Output Power (W): 24 | No. Outputs: D | Case: DIN Rail | Size: 3.78 x 2.13 x 1.35" | Get a Quote |
| PSAJM-24D15DN | Input Voltage: 85~264 | Output Voltage: 15, -15 | Output Current: ±800mA | Output Power (W): 24 | No. Outputs: D | Case: DIN Rail | Size: 3.78 x 2.13 x 1.35" | Get a Quote |
| Specification | Value |
|---|---|
| Input | |
| Input Voltage (Nominal): | 115/230 |
| Input Voltage Range: | 85~264 |
| Input Frequency: | 47 to 440Hz |
| Output | |
| Output Voltage: | -15, -12, 5, 9, 12, 15, 24 |
| Voltage Accuracy: | ±2.0% |
| Output Current: | -1300mA, -1660mA, 1300mA, 1660mA, 2660mA, 3330mA, 8000mA |
| Output Power (Watts): | 40 |
| Short Circuit Protection: | Automatic Recovery |
| Over Voltage Protection: | Zener Diode Clamp |
| General | |
| Efficiency: | Up to 85% |
| Isolation: | 4000VACrms |
| Environmental | |
| Operating Temperature: | -40 to +80ºC |
| Storage Temperature: | -40 to +95ºC |
| Physical | |
| Weight: | PCB Mount: 4.83oz (137g) Chassis Mount: 5.19oz (147g) DIN Rail Mount: 7.09oz (201) |
| Dimensions: | PCB Mount: 2.91 x 2.13 x 0.77in Chassis Mount: 3.78 x 2.13 x 0.92in DIN Rail Mount: 3.78 x 2.13 x 1.35in |
| Case Material: | Plastic Resin (Flammability to UL 94V-0 rated) |
| Notes & safety | |
| Notes: | 1. This product is not designed for use in critical life support systems, equipment used in hazardous environment, nuclear control systems or other such applications which necessitate specific safety and regulatory standards other than the ones listed in this datasheet. 2. Long term overload conditions may cause damage. 3. Natural convection is about 20LFM but is not equal to still air (0LFM). 4. Safety approvals cover frequency 47-63Hz. 5. Other input and output voltages may be available, please contact factory. 6. It is recommended to protect the converter by a slow blow fuse in the input supply line. 7. This product is Listed to applicable standards and requirements by UL. *Due to advances in technology, specifications subject to change without notice. |
| Safety Approvals: | UL/cUL 60950-1, CSA C22.2 No 60950-1, ANSI/AAMI ES60601-2, CAN/CSA-C22.2 No. 60601-1, IEC/EN 60950-1, IEC/EN 60601-1 3rd Edition 2xMOPP, UL/cUL 60950-1 Recognition (UL Certificate), IEC/EN 60950-1(CB Report), ANSI/AAMI ES60601-1 2xMOPP recognition (UL certificate), IEC/EN 60601-1 3rd Edition (CB Report) |
| RoHS Compliance: | Yes |
