DTCGSW30
The DTCGSW30 series of AC DC desktop power supplies offers 27 watts of continuous output power. This series consists of single output models with an input voltage range of 90~264VAC and output voltages ranging from 5~12V. Three different wall plugs are available for this series, European, US, and British plugs. All models are protected against over current and short circuit conditions, and all have UL, FCC, CEC, CE, EUP, and BS1363 safety approvals. Please call factory for ordering details.
| Model Number |
Input Voltage |
Output Voltage |
Output Current |
Output Power (W) |
No. Outputs |
Case | Size | |
|---|---|---|---|---|---|---|---|---|
| DTCGSW30-090-2000 | Input Voltage: 90~264 | Output Voltage: 9 | Output Current: 3000mA | Output Power (W): 18 | No. Outputs: S | Case: Desktop | Size: 3.46" x 1.97" x 1.81" | Get a Quote |
| DTCGSW30-120-1500 | Input Voltage: 90~264 | Output Voltage: 12 | Output Current: 1500mA | Output Power (W): 18 | No. Outputs: S | Case: Desktop | Size: 3.46" x 1.97" x 1.81" | Get a Quote |
| DTCGSW30-180-1000 | Input Voltage: 90~264 | Output Voltage: 18 | Output Current: 1000mA | Output Power (W): 18 | No. Outputs: S | Case: Desktop | Size: 3.46" x 1.97" x 1.81" | Get a Quote |
| DTCGSW30-120-2000 | Input Voltage: 90~264 | Output Voltage: 12 | Output Current: 2000mA | Output Power (W): 24 | No. Outputs: S | Case: Desktop | Size: 3.46" x 1.97" x 1.81" | Get a Quote |
| DTCGSW30-240-1000 | Input Voltage: 90~264 | Output Voltage: 24 | Output Current: 1000mA | Output Power (W): 24 | No. Outputs: S | Case: Desktop | Size: 3.46" x 1.97" x 1.81" | Get a Quote |
| DTCGSW30-090-3000 | Input Voltage: 90~264 | Output Voltage: 9 | Output Current: 2000mA | Output Power (W): 27 | No. Outputs: S | Case: Desktop | Size: 3.46" x 1.97" x 1.81" | Get a Quote |
| DTCGSW30-120-2500 | Input Voltage: 90~264 | Output Voltage: 12 | Output Current: 2500mA | Output Power (W): 30 | No. Outputs: S | Case: Desktop | Size: 3.46" x 1.97" x 1.81" | Get a Quote |
| Specification | Value |
|---|---|
| Input | |
| Input Voltage (Nominal): | 100~240 |
| Input Voltage Range: | 90~264 |
| Input Frequency: | 47~63Hz |
| Output | |
| Output Voltage: | 9, 12, 18, 24 |
| Output Current: | 2000mA, 3000mA, 1500mA, 2500mA, 1000mA |
| Output Power (Watts): | 18, 24, 27, 30 |
| Short Circuit Protection: | Automatic Recovery |
| General | |
| Environmental | |
| Operating Temperature: | 10 to 40°C |
| Storage Temperature: | -20 to 80°C |
| Physical | |
| Weight: | 5.29oz |
| Dimensions: | 3.46" x 1.97" x 1.81" |
| Notes & safety | |
| Notes: | (1) Ripple and Noise is measured by 20MHz bandwidth oscilloscope and the output paralleled a 0.1uF ceramic capacitor and a 10uF electrolysis capacitor. (Test under the condition of rated input and rated output) (2) Efficiency measured Nominal input. Efficiency indicated is minimum. (3) Regulatory standards for 5V-9V Models (4) This product is Listed to applicable standards and requirements by UL. Due to advances in technology, specifications are subject to change without notice. |
| Safety Approvals: | UL, CUL, FCC, CE, GS, KC, PSE, CCC, SAA, C-Tick, CB |
| RoHS Compliance: | Yes |
| Energy Star Compliance: | Level VI |
