PSLH

The PSLH series of AC/DC converters offers 5-25 watts of output power in either a PCB, chassis mount, or DIN rail mounted package. This series consists of single output models with a wide input voltage range of 85~305VAC (100~430VDC). Each model in this series features a wide operating temperature range, isolation voltage of 3000VAC, as well as short circuit, over current, and over voltage protection. This series has IEC60950, EN60950, and UL60950 safety approvals and UL/CE/CB certifications. Please contact factory for order details.

• Wide Input Voltage Range 85~305VAC (100~430VDC) • Wide Operating Temperature Range • PCB, Chassis Mount, or DIN Rail Mounting Available • Short Circuit, Over Current, and Over Voltage Protection • Conversion Efficiency up to 87% • Isolation Voltage of 3000VAC • UL/CE/CB Certifications • IEC60950, EN60950, and UL60950 Safety Approvals
Model
Number
Input
Voltage
Output
Voltage
Output
Current
Output
Power (W)
No.
Outputs
Case
PSLH05-03SA1 Input Voltage: 85~305 Output Voltage: 3.3 Output Current: 1250mA Output Power (W): 4 No. Outputs: S Case: PCB Mount Get a Quote
PSLH05-03SA2 Input Voltage: 85~305 Output Voltage: 3.3 Output Current: 1250mA Output Power (W): 4 No. Outputs: S Case: Chassis Mount Get a Quote
PSLH05-03SA3 Input Voltage: 85~305 Output Voltage: 3.3 Output Current: 1250mA Output Power (W): 4 No. Outputs: S Case: Chassis Mount Get a Quote
PSLH05-03SA4 Input Voltage: 85~305 Output Voltage: 3.3 Output Current: 1250mA Output Power (W): 4 No. Outputs: S Case: DIN Rail Get a Quote
PSLH05-05SA1 Input Voltage: 85~305 Output Voltage: 5 Output Current: 1000mA Output Power (W): 5 No. Outputs: S Case: PCB Mount Get a Quote
PSLH05-05SA2 Input Voltage: 85~305 Output Voltage: 5 Output Current: 1000mA Output Power (W): 5 No. Outputs: S Case: Chassis Mount Get a Quote
PSLH05-05SA3 Input Voltage: 85~305 Output Voltage: 5 Output Current: 1000mA Output Power (W): 5 No. Outputs: S Case: Chassis Mount Get a Quote
PSLH05-05SA4 Input Voltage: 85~305 Output Voltage: 5 Output Current: 1000mA Output Power (W): 5 No. Outputs: S Case: DIN Rail Get a Quote
PSLH05-09SA1 Input Voltage: 85~305 Output Voltage: 9 Output Current: 550mA Output Power (W): 5 No. Outputs: S Case: PCB Mount Get a Quote
PSLH05-09SA2 Input Voltage: 85~305 Output Voltage: 9 Output Current: 550mA Output Power (W): 5 No. Outputs: S Case: Chassis Mount Get a Quote
PSLH05-09SA3 Input Voltage: 85~305 Output Voltage: 9 Output Current: 550mA Output Power (W): 5 No. Outputs: S Case: Chassis Mount Get a Quote
PSLH05-09SA4 Input Voltage: 85~305 Output Voltage: 9 Output Current: 550mA Output Power (W): 5 No. Outputs: S Case: DIN Rail Get a Quote
PSLH05-12SA1 Input Voltage: 85~305 Output Voltage: 12 Output Current: 420mA Output Power (W): 5 No. Outputs: S Case: PCB Mount Get a Quote
PSLH05-12SA2 Input Voltage: 85~305 Output Voltage: 12 Output Current: 420mA Output Power (W): 5 No. Outputs: S Case: Chassis Mount Get a Quote
PSLH05-12SA3 Input Voltage: 85~305 Output Voltage: 12 Output Current: 420mA Output Power (W): 5 No. Outputs: S Case: Chassis Mount Get a Quote
PSLH05-12SA4 Input Voltage: 85~305 Output Voltage: 12 Output Current: 420mA Output Power (W): 5 No. Outputs: S Case: DIN Rail Get a Quote
PSLH05-15SA1 Input Voltage: 85~305 Output Voltage: 15 Output Current: 330mA Output Power (W): 5 No. Outputs: S Case: PCB Mount Get a Quote
PSLH05-15SA2 Input Voltage: 85~305 Output Voltage: 15 Output Current: 330mA Output Power (W): 5 No. Outputs: S Case: Chassis Mount Get a Quote
PSLH05-15SA3 Input Voltage: 85~305 Output Voltage: 15 Output Current: 330mA Output Power (W): 5 No. Outputs: S Case: Chassis Mount Get a Quote
PSLH05-15SA4 Input Voltage: 85~305 Output Voltage: 15 Output Current: 330mA Output Power (W): 5 No. Outputs: S Case: DIN Rail Get a Quote
PSLH05-24SA1 Input Voltage: 85~305 Output Voltage: 24 Output Current: 230mA Output Power (W): 5 No. Outputs: S Case: PCB Mount Get a Quote
PSLH05-24SA2 Input Voltage: 85~305 Output Voltage: 24 Output Current: 230mA Output Power (W): 5 No. Outputs: S Case: Chassis Mount Get a Quote
PSLH05-24SA3 Input Voltage: 85~305 Output Voltage: 24 Output Current: 230mA Output Power (W): 5 No. Outputs: S Case: Chassis Mount Get a Quote
PSLH05-24SA4 Input Voltage: 85~305 Output Voltage: 24 Output Current: 230mA Output Power (W): 5 No. Outputs: S Case: DIN Rail Get a Quote
PSLH10-03SA1 Input Voltage: 85~305 Output Voltage: 3.3 Output Current: 2000mA Output Power (W): 6.6 No. Outputs: S Case: PCB Mount Get a Quote
PSLH10-03SA2 Input Voltage: 85~305 Output Voltage: 3.3 Output Current: 2000mA Output Power (W): 6.6 No. Outputs: S Case: Chassis Mount Get a Quote
PSLH10-03SA3 Input Voltage: 85~305 Output Voltage: 3.3 Output Current: 2000mA Output Power (W): 6.6 No. Outputs: S Case: Chassis Mount Get a Quote
PSLH10-03SA4 Input Voltage: 85~305 Output Voltage: 3.3 Output Current: 2000mA Output Power (W): 6.6 No. Outputs: S Case: DIN Rail Get a Quote
PSLH15-03SA1 Input Voltage: 85~305 Output Voltage: 3.3 Output Current: 3000mA Output Power (W): 9.9 No. Outputs: S Case: PCB Mount Get a Quote
PSLH15-03SA2 Input Voltage: 85~305 Output Voltage: 3.3 Output Current: 3000mA Output Power (W): 9.9 No. Outputs: S Case: Chassis Mount Get a Quote
PSLH15-03SA3 Input Voltage: 85~305 Output Voltage: 3.3 Output Current: 3000mA Output Power (W): 9.9 No. Outputs: S Case: Chassis Mount Get a Quote
PSLH15-03SA4 Input Voltage: 85~305 Output Voltage: 3.3 Output Current: 3000mA Output Power (W): 9.9 No. Outputs: S Case: DIN Rail Get a Quote
PSLH10-05SA1 Input Voltage: 85~305 Output Voltage: 5 Output Current: 2000mA Output Power (W): 10 No. Outputs: S Case: PCB Mount Get a Quote
PSLH10-05SA2 Input Voltage: 85~305 Output Voltage: 5 Output Current: 2000mA Output Power (W): 10 No. Outputs: S Case: Chassis Mount Get a Quote
PSLH10-05SA3 Input Voltage: 85~305 Output Voltage: 5 Output Current: 2000mA Output Power (W): 10 No. Outputs: S Case: Chassis Mount Get a Quote
PSLH10-05SA4 Input Voltage: 85~305 Output Voltage: 5 Output Current: 2000mA Output Power (W): 10 No. Outputs: S Case: DIN Rail Get a Quote
PSLH10-09SA1 Input Voltage: 85~305 Output Voltage: 9 Output Current: 1100mA Output Power (W): 10 No. Outputs: S Case: PCB Mount Get a Quote
PSLH10-09SA2 Input Voltage: 85~305 Output Voltage: 9 Output Current: 1100mA Output Power (W): 10 No. Outputs: S Case: Chassis Mount Get a Quote
PSLH10-09SA3 Input Voltage: 85~305 Output Voltage: 9 Output Current: 1100mA Output Power (W): 10 No. Outputs: S Case: Chassis Mount Get a Quote
PSLH10-09SA4 Input Voltage: 85~305 Output Voltage: 9 Output Current: 1100mA Output Power (W): 10 No. Outputs: S Case: DIN Rail Get a Quote
PSLH10-12SA1 Input Voltage: 85~305 Output Voltage: 12 Output Current: 900mA Output Power (W): 10 No. Outputs: S Case: PCB Mount Get a Quote
PSLH10-12SA2 Input Voltage: 85~305 Output Voltage: 12 Output Current: 900mA Output Power (W): 10 No. Outputs: S Case: Chassis Mount Get a Quote
PSLH10-12SA3 Input Voltage: 85~305 Output Voltage: 12 Output Current: 900mA Output Power (W): 10 No. Outputs: S Case: Chassis Mount Get a Quote
PSLH10-12SA4 Input Voltage: 85~305 Output Voltage: 12 Output Current: 900mA Output Power (W): 10 No. Outputs: S Case: DIN Rail Get a Quote
PSLH10-15SA1 Input Voltage: 85~305 Output Voltage: 15 Output Current: 700mA Output Power (W): 10 No. Outputs: S Case: PCB Mount Get a Quote
PSLH10-15SA2 Input Voltage: 85~305 Output Voltage: 15 Output Current: 700mA Output Power (W): 10 No. Outputs: S Case: Chassis Mount Get a Quote
PSLH10-15SA3 Input Voltage: 85~305 Output Voltage: 15 Output Current: 700mA Output Power (W): 10 No. Outputs: S Case: Chassis Mount Get a Quote
PSLH10-15SA4 Input Voltage: 85~305 Output Voltage: 15 Output Current: 700mA Output Power (W): 10 No. Outputs: S Case: DIN Rail Get a Quote
PSLH10-24SA1 Input Voltage: 85~305 Output Voltage: 24 Output Current: 450mA Output Power (W): 10 No. Outputs: S Case: PCB Mount Get a Quote
PSLH10-24SA2 Input Voltage: 85~305 Output Voltage: 24 Output Current: 450mA Output Power (W): 10 No. Outputs: S Case: Chassis Mount Get a Quote
PSLH10-24SA3 Input Voltage: 85~305 Output Voltage: 24 Output Current: 450mA Output Power (W): 10 No. Outputs: S Case: Chassis Mount Get a Quote
PSLH10-24SA4 Input Voltage: 85~305 Output Voltage: 24 Output Current: 450mA Output Power (W): 10 No. Outputs: S Case: DIN Rail Get a Quote
PSLH20-03SA1 Input Voltage: 85~305 Output Voltage: 3.3 Output Current: 3500mA Output Power (W): 13.5 No. Outputs: S Case: PCB Mount Get a Quote
PSLH20-03SA2 Input Voltage: 85~305 Output Voltage: 3.3 Output Current: 3500mA Output Power (W): 13.5 No. Outputs: S Case: Chassis Mount Get a Quote
PSLH20-03SA3 Input Voltage: 85~305 Output Voltage: 3.3 Output Current: 3500mA Output Power (W): 13.5 No. Outputs: S Case: Chassis Mount Get a Quote
PSLH20-03SA4 Input Voltage: 85~305 Output Voltage: 3.3 Output Current: 3500mA Output Power (W): 13.5 No. Outputs: S Case: DIN Rail Get a Quote
PSLH25-03SA1 Input Voltage: 85~305 Output Voltage: 3.3 Output Current: 4100mA Output Power (W): 13.5 No. Outputs: S Case: PCB Mount Get a Quote
PSLH25-03SA2 Input Voltage: 85~305 Output Voltage: 3.3 Output Current: 4100mA Output Power (W): 13.5 No. Outputs: S Case: Chassis Mount Get a Quote
PSLH25-03SA3 Input Voltage: 85~305 Output Voltage: 3.3 Output Current: 4100mA Output Power (W): 13.5 No. Outputs: S Case: Chassis Mount Get a Quote
PSLH25-03SA4 Input Voltage: 85~305 Output Voltage: 3.3 Output Current: 4100mA Output Power (W): 13.5 No. Outputs: S Case: DIN Rail Get a Quote
PSLH15-05SA1 Input Voltage: 85~305 Output Voltage: 5 Output Current: 2800mA Output Power (W): 14 No. Outputs: S Case: PCB Mount Get a Quote
PSLH15-05SA2 Input Voltage: 85~305 Output Voltage: 5 Output Current: 2800mA Output Power (W): 14 No. Outputs: S Case: Chassis Mount Get a Quote
PSLH15-05SA3 Input Voltage: 85~305 Output Voltage: 5 Output Current: 2800mA Output Power (W): 14 No. Outputs: S Case: Chassis Mount Get a Quote
PSLH15-05SA4 Input Voltage: 85~305 Output Voltage: 9 Output Current: 2800mA Output Power (W): 14 No. Outputs: S Case: DIN Rail Get a Quote
PSLH15-09SA1 Input Voltage: 85~305 Output Voltage: 9 Output Current: 1600mA Output Power (W): 15 No. Outputs: S Case: PCB Mount Get a Quote
PSLH15-09SA2 Input Voltage: 85~305 Output Voltage: 9 Output Current: 1600mA Output Power (W): 15 No. Outputs: S Case: Chassis Mount Get a Quote
PSLH15-09SA3 Input Voltage: 85~305 Output Voltage: 9 Output Current: 1600mA Output Power (W): 15 No. Outputs: S Case: Chassis Mount Get a Quote
PSLH15-09SA4 Input Voltage: 85~305 Output Voltage: 9 Output Current: 1600mA Output Power (W): 15 No. Outputs: S Case: DIN Rail Get a Quote
PSLH15-12SA1 Input Voltage: 85~305 Output Voltage: 12 Output Current: 1250mA Output Power (W): 15 No. Outputs: S Case: PCB Mount Get a Quote
PSLH15-12SA2 Input Voltage: 85~305 Output Voltage: 12 Output Current: 1250mA Output Power (W): 15 No. Outputs: S Case: Chassis Mount Get a Quote
PSLH15-12SA3 Input Voltage: 85~305 Output Voltage: 12 Output Current: 1250mA Output Power (W): 15 No. Outputs: S Case: Chassis Mount Get a Quote
PSLH15-12SA4 Input Voltage: 85~305 Output Voltage: 12 Output Current: 1250mA Output Power (W): 15 No. Outputs: S Case: DIN Rail Get a Quote
PSLH15-15SA1 Input Voltage: 85~305 Output Voltage: 15 Output Current: 1000mA Output Power (W): 15 No. Outputs: S Case: PCB Mount Get a Quote
PSLH15-15SA2 Input Voltage: 85~305 Output Voltage: 15 Output Current: 1000mA Output Power (W): 15 No. Outputs: S Case: Chassis Mount Get a Quote
PSLH15-15SA3 Input Voltage: 85~305 Output Voltage: 15 Output Current: 1000mA Output Power (W): 15 No. Outputs: S Case: Chassis Mount Get a Quote
PSLH15-15SA4 Input Voltage: 85~305 Output Voltage: 15 Output Current: 1000mA Output Power (W): 15 No. Outputs: S Case: DIN Rail Get a Quote
PSLH15-24SA1 Input Voltage: 85~305 Output Voltage: 24 Output Current: 625mA Output Power (W): 15 No. Outputs: S Case: PCB Mount Get a Quote
PSLH15-24SA2 Input Voltage: 85~305 Output Voltage: 24 Output Current: 625mA Output Power (W): 15 No. Outputs: S Case: Chassis Mount Get a Quote
PSLH15-24SA3 Input Voltage: 85~305 Output Voltage: 24 Output Current: 625mA Output Power (W): 15 No. Outputs: S Case: Chassis Mount Get a Quote
PSLH15-24SA4 Input Voltage: 85~305 Output Voltage: 24 Output Current: 625mA Output Power (W): 15 No. Outputs: S Case: DIN Rail Get a Quote
PSLH15-48SA1 Input Voltage: 85~305 Output Voltage: 48 Output Current: 320mA Output Power (W): 15 No. Outputs: S Case: PCB Mount Get a Quote
PSLH15-48SA2 Input Voltage: 85~305 Output Voltage: 48 Output Current: 320mA Output Power (W): 15 No. Outputs: S Case: Chassis Mount Get a Quote
PSLH15-48SA3 Input Voltage: 85~305 Output Voltage: 48 Output Current: 320mA Output Power (W): 15 No. Outputs: S Case: Chassis Mount Get a Quote
PSLH20-48SA4 Input Voltage: 85~305 Output Voltage: 48 Output Current: 320mA Output Power (W): 15 No. Outputs: S Case: DIN Rail Get a Quote
PSLH20-05SA1 Input Voltage: 85~305 Output Voltage: 5 Output Current: 3500mA Output Power (W): 17.5 No. Outputs: S Case: PCB Mount Get a Quote
PSLH20-05SA2 Input Voltage: 85~305 Output Voltage: 5 Output Current: 3500mA Output Power (W): 17.5 No. Outputs: S Case: Chassis Mount Get a Quote
PSLH20-05SA3 Input Voltage: 85~305 Output Voltage: 5 Output Current: 3500mA Output Power (W): 17.5 No. Outputs: S Case: Chassis Mount Get a Quote
PSLH20-05SA4 Input Voltage: 85~305 Output Voltage: 5 Output Current: 3500mA Output Power (W): 17.5 No. Outputs: S Case: DIN Rail Get a Quote
PSLH20-09SA1 Input Voltage: 85~305 Output Voltage: 9 Output Current: 2100mA Output Power (W): 20 No. Outputs: S Case: PCB Mount Get a Quote
PSLH20-09SA2 Input Voltage: 85~305 Output Voltage: 9 Output Current: 2100mA Output Power (W): 20 No. Outputs: S Case: Chassis Mount Get a Quote
PSLH20-09SA3 Input Voltage: 85~305 Output Voltage: 9 Output Current: 2100mA Output Power (W): 20 No. Outputs: S Case: Chassis Mount Get a Quote
PSLH20-09SA4 Input Voltage: 85~305 Output Voltage: 9 Output Current: 2100mA Output Power (W): 20 No. Outputs: S Case: DIN Rail Get a Quote
PSLH20-12SA1 Input Voltage: 85~305 Output Voltage: 12 Output Current: 1600mA Output Power (W): 20 No. Outputs: S Case: PCB Mount Get a Quote
PSLH20-12SA2 Input Voltage: 85~305 Output Voltage: 12 Output Current: 1600mA Output Power (W): 20 No. Outputs: S Case: Chassis Mount Get a Quote
PSLH20-12SA3 Input Voltage: 85~305 Output Voltage: 12 Output Current: 1600mA Output Power (W): 20 No. Outputs: S Case: Chassis Mount Get a Quote
PSLH20-12SA4 Input Voltage: 85~305 Output Voltage: 12 Output Current: 1600mA Output Power (W): 20 No. Outputs: S Case: DIN Rail Get a Quote
PSLH20-15SA1 Input Voltage: 85~305 Output Voltage: 15 Output Current: 1300mA Output Power (W): 20 No. Outputs: S Case: PCB Mount Get a Quote
PSLH20-15SA2 Input Voltage: 85~305 Output Voltage: 15 Output Current: 1300mA Output Power (W): 20 No. Outputs: S Case: Chassis Mount Get a Quote
PSLH20-15SA3 Input Voltage: 85~305 Output Voltage: 15 Output Current: 1300mA Output Power (W): 20 No. Outputs: S Case: Chassis Mount Get a Quote
PSLH20-15SA4 Input Voltage: 85~305 Output Voltage: 15 Output Current: 1300mA Output Power (W): 20 No. Outputs: S Case: DIN Rail Get a Quote
PSLH20-24SA1 Input Voltage: 85~305 Output Voltage: 24 Output Current: 850mA Output Power (W): 20 No. Outputs: S Case: PCB Mount Get a Quote
PSLH20-24SA2 Input Voltage: 85~305 Output Voltage: 24 Output Current: 850mA Output Power (W): 20 No. Outputs: S Case: Chassis Mount Get a Quote
PSLH20-24SA3 Input Voltage: 85~305 Output Voltage: 24 Output Current: 850mA Output Power (W): 20 No. Outputs: S Case: Chassis Mount Get a Quote
PSLH20-24SA4 Input Voltage: 85~305 Output Voltage: 24 Output Current: 850mA Output Power (W): 20 No. Outputs: S Case: DIN Rail Get a Quote
PSLH25-05SA1 Input Voltage: 85~305 Output Voltage: 5 Output Current: 4100mA Output Power (W): 20.5 No. Outputs: S Case: PCB Mount Get a Quote
PSLH25-05SA2 Input Voltage: 85~305 Output Voltage: 5 Output Current: 4100mA Output Power (W): 20.5 No. Outputs: S Case: Chassis Mount Get a Quote
PSHL25-05SA3 Input Voltage: 85~305 Output Voltage: 5 Output Current: 4100mA Output Power (W): 20.5 No. Outputs: S Case: Chassis Mount Get a Quote
PSLH25-05SA4 Input Voltage: 85~305 Output Voltage: 5 Output Current: 4100mA Output Power (W): 20.5 No. Outputs: S Case: DIN Rail Get a Quote
PSLH25-09SA1 Input Voltage: 85~305 Output Voltage: 9 Output Current: 2500mA Output Power (W): 25 No. Outputs: S Case: PCB Mount Get a Quote
PSLH25-09SA2 Input Voltage: 85~305 Output Voltage: 9 Output Current: 2500mA Output Power (W): 25 No. Outputs: S Case: Chassis Mount Get a Quote
PSLH25-09SA3 Input Voltage: 85~305 Output Voltage: 9 Output Current: 2500mA Output Power (W): 25 No. Outputs: S Case: Chassis Mount Get a Quote
PSLH25-09SA4 Input Voltage: 85~305 Output Voltage: 9 Output Current: 2500mA Output Power (W): 25 No. Outputs: S Case: DIN Rail Get a Quote
PSLH25-12SA1 Input Voltage: 85~305 Output Voltage: 12 Output Current: 2100mA Output Power (W): 25 No. Outputs: S Case: PCB Mount Get a Quote
PSLH25-12SA2 Input Voltage: 85~305 Output Voltage: 12 Output Current: 2100mA Output Power (W): 25 No. Outputs: S Case: Chassis Mount Get a Quote
PSLH25-12SA3 Input Voltage: 85~305 Output Voltage: 12 Output Current: 2100mA Output Power (W): 25 No. Outputs: S Case: Chassis Mount Get a Quote
PSLH25-15SA4 Input Voltage: 85~305 Output Voltage: 12 Output Current: 2100mA Output Power (W): 25 No. Outputs: S Case: DIN Rail Get a Quote
PSLH25-15SA1 Input Voltage: 85~305 Output Voltage: 15 Output Current: 1600mA Output Power (W): 25 No. Outputs: S Case: PCB Mount Get a Quote
PSLH25-15SA2 Input Voltage: 85~305 Output Voltage: 15 Output Current: 1600mA Output Power (W): 25 No. Outputs: S Case: Chassis Mount Get a Quote
PSLH25-15SA3 Input Voltage: 85~305 Output Voltage: 15 Output Current: 1600mA Output Power (W): 25 No. Outputs: S Case: Chassis Mount Get a Quote
PSLH25-15SA4 Input Voltage: 85~305 Output Voltage: 15 Output Current: 1600mA Output Power (W): 25 No. Outputs: S Case: DIN Rail Get a Quote
PSLH25-24SA1 Input Voltage: 85~305 Output Voltage: 24 Output Current: 1100mA Output Power (W): 25 No. Outputs: S Case: PCB Mount Get a Quote
PSLH25-24SA2 Input Voltage: 85~305 Output Voltage: 24 Output Current: 1100mA Output Power (W): 25 No. Outputs: S Case: Chassis Mount Get a Quote
PSLH25-24SA3 Input Voltage: 85~305 Output Voltage: 24 Output Current: 1100mA Output Power (W): 25 No. Outputs: S Case: Chassis Mount Get a Quote
PSLH25-24SA4 Input Voltage: 85~305 Output Voltage: 24 Output Current: 1100mA Output Power (W): 25 No. Outputs: S Case: DIN Rail Get a Quote
PSLH25-48SA1 Input Voltage: 85~305 Output Voltage: 48 Output Current: 500mA Output Power (W): 25 No. Outputs: S Case: PCB Mount Get a Quote
PSLH25-48SA2 Input Voltage: 85~305 Output Voltage: 48 Output Current: 500mA Output Power (W): 25 No. Outputs: S Case: Chassis Mount Get a Quote
PSLH25-48SA3 Input Voltage: 85~305 Output Voltage: 48 Output Current: 500mA Output Power (W): 25 No. Outputs: S Case: Chassis Mount Get a Quote
PSLH25-48SA4 Input Voltage: 85~305 Output Voltage: 48 Output Current: 500mA Output Power (W): 25 No. Outputs: S Case: DIN Rail Get a Quote
Specification Value
Input
Input Voltage (Nominal): 115/230
Input Voltage Range: 85~305VAC
Input Frequency: 47 to 65Hz
Output
Output Voltage: 3.3, 5, 9, 12, 15, 24, 48
Voltage Accuracy: ±2%
Output Current: 230mA, 320mA, 330mA, 420mA, 450mA, 500mA, 550mA, 625mA, 700mA, 850mA, 900mA, 1000mA, 1100mA, 1250mA, 1300mA, 1600mA, 2000mA, 2100mA, 2500mA, 2800mA, 3000mA, 3500mA, 4100mA
Output Power (Watts): 4, 5, 6.6, 10, 9.9, 13.5, 14, 15, 13.5, 17.5, 20, 20.5, 25
Short Circuit Protection: Hiccup, Continuous, Self-Recovery
Over Voltage Protection: 3.3 & 5VDC Outputs: ≤7.5VDC
9VDC Output: ≤12VDC
12 & 15VDC Outputs: ≤20VDC
24VDC Output: ≤30VDC
48VDC Output: ≤60VDC
General
Efficiency: Up to 87%
Isolation: Input-Output: 3000VAC
Input-GND: 2000VAC
Environmental
Operating Temperature: -40 to +70ºC
Storage Temperature: PSHL05/PSLH10/PSLH15: -40 to +105ºC
PSLH20/PSLH25: -40 to +85ºC
Physical
Weight: PCB Mount: 2.65-4.23oz (75-120g)
Chassis Mount: 4.23-6oz (125-170g)
DIN Rail Mount: 5.82-7.41oz (165-210g)
Dimensions: PCB Mount: 2.16-2.76in x 1.77-1.89in x 0.83-0.93in (55-70mm x 45-48mm x 21-23.5mm)
Chassis Mount Option 1: 3.78in x 2.13in x 1.16-1.25in (96.1mm x 54mm x 29.5-32mm)
Chassis Mount Option 2: 3.90in x 2.13in x 1.16-1.25in (99mm x 54mm x 29.5-32mm)
DIN Rail Mount: 3.78in x 2.13in x 1.34-1.44in (96.1mm x 54mm x 34.1-36.6mm)
Case Material: Black Flame-Retardant & Heat-Resistance Plastic (UL94-V0)
Notes & safety
Notes: 1. “X” in model number represents mounting options. “X” can either be “A1” for PCB Mounting, “A2” for Chassis Mount option 1, “A3” for Chassis Mount option 2, or “A4” for DIN rail mount.
2. Special package series include fuse.
3. Ripple & Noise is tested with “parallel cable” method. Contact factory for more information.
4. There is no pin GND on PSLH15 models.
5. If the product is not operating within required load range, product performance cannot be guaranteed to comply with all parameters in the datasheet.
6. Customization available.
7. Performance indexes of the product models listed are as recorded in data sheet. Indexes of non-standard model products will exceed the mentioned requirements. Please contact factory for more information.
*Due to advances in technology, specifications subject to change without notice.
Safety Approvals: IEC60950, EN60950, UL60950
