The DTIPU68 series of AC DC power suppliesprovides 80 watts peak output power. This series consists of single output supplies with a universal input range of 90~264VAC and an IEC-320-C14 AC input connector. Some features include no load power consumption < 0.5, -20°C~+70°C operating temperature range, and over voltage and over current protection. All supplies are CEC, Energy Star, and UL 94V-1 min compliant. This series meets FCC-Part-15 class B and CISPR-22 class B emission limits and have UL/c-UL (UL 60950-1) and TUV/GS (EN 60950-1) approvals. This series also meets new CE requirements. With the delay buffer duration of over current protection a large amount of current can be acquired and the LPS safety requirement can be met which is very useful for motor drivers/devices (peak load). All models are 100% burn-in tested.

● 100% Burn-in ● Class I Insulation ● IEC-320-C14 Input Inlet ● CEC and Energy Star Compliant ● No Load Power Consumption < 0.5 ● Optional Output Connectors Available ● Over Voltage and Over Current Protection ● Over Voltage Protection (Crowbar Design) ● -20°C ~ 70°C Operating Temperature Range ● Wide Input Voltage Range: 90 to 264VAC, 47~63Hz
Power (W)
Case Size
DTIPU68-105 Input Voltage: 90~264 Output Voltage: 13 Output Current: 6.66 mA Output Power (W): 80 No. Outputs: S Case: Desktop Size: 6.61" x 3.06" x 1.77" Get a Quote
DTIPU68-108 Input Voltage: 90~264 Output Voltage: 27 Output Current: 3.33 mA Output Power (W): 80 No. Outputs: S Case: Desktop Size: 6.61" x 3.06" x 1.77" Get a Quote
Specification Value
Input Voltage (Nominal): 115/230
Input Voltage Range: 90~264
Input Frequency: 47-63 Hz
Output Voltage: 13, 27
Output Current: 3.33mA, 6.66mA
Output Power (Watts): 80
Over Voltage Protection: 112~132%
Efficiency: 84%
Isolation: 4242VDC min
Operating Temperature: 20 to 70°C
Storage Temperature: -40 to 85°C
Weight: 10 oz.
Dimensions: 6.61" x 3.06" x 1.77" (168 x 77.6 x 45 mm)
Notes & safety
Notes: 1. The output voltage is specified as a range (Ex: 21 ~ 27VDC); the preset voltage will be set as standard models if nothing different is requested. Please contact factory for ordering details.
2. The output voltage ≥ 12VDC can meet CEC approvals.
3. An AWG#18/4ft output cable is required to use in order to meet the total regulation on each model. The total regulation will change if a different output cable is used.
4. Optional output connectors are available. Please call factory for ordering details.
Due to advances in technology, specifications subject to change without notice.
RoHS Compliance: Yes
TUV Efficiency Level: TUV/GS EN60950-1
Energy Star Compliance: Level IV
