WMBA018

The WMBA018 series of AC/DC wall mount power supplies provides 18 watts of continuous output power. This series consists of models with a 90~264VAC input voltage range and output voltages ranging from 5V to 56V. All units are RoHS and efficiency Level VI compliant and meet IEC/EN60950-1, UL/CUL60950-1, BSMI, CCC, KC, PSE, SAA safety approvals. The WMBA018 series offers 3 plug types: US, Australia, and UK as well as an in-line (with or without USB) or side entry case.

• Universal Input 90~264VAC • DoE/ErP Level VI Efficiency Compliant • RoHS Compliant • In Line or Side Entry Case • Interchangeable plug for US, EU, SAA, UK 3C type • MTBF > 30,000 hours • Class II
Model
Number
Input
Voltage
Output
Voltage
Output
Current
Output
Power (W)
No.
Outputs
Case
WMBA018005-1U Input Voltage: 90~264 Output Voltage: 5 Output Current: 3.0A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018005-2U Input Voltage: 90~264 Output Voltage: 5 Output Current: 3.0A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018005-3U Input Voltage: 90~264 Output Voltage: 5 Output Current: 3.0A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018005-1K Input Voltage: 90~264 Output Voltage: 5 Output Current: 3.0A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018005-2K Input Voltage: 90~264 Output Voltage: 5 Output Current: 3.0A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018005-3K Input Voltage: 90~264 Output Voltage: 5 Output Current: 3.0A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018005-1A Input Voltage: 90~264 Output Voltage: 5 Output Current: 3.0A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018005-2A Input Voltage: 90~264 Output Voltage: 5 Output Current: 3.0A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018005-3A Input Voltage: 90~264 Output Voltage: 5 Output Current: 3.0A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018089-1U Input Voltage: 90~264 Output Voltage: 8.9 Output Current: 3.0A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018089-2U Input Voltage: 90~264 Output Voltage: 8.9 Output Current: 3.0A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018089-3U Input Voltage: 90~264 Output Voltage: 8.9 Output Current: 3.0A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018089-1K Input Voltage: 90~264 Output Voltage: 8.9 Output Current: 3.0A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018089-2K Input Voltage: 90~264 Output Voltage: 8.9 Output Current: 3.0A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018089-3K Input Voltage: 90~264 Output Voltage: 8.9 Output Current: 3.0A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018089-1A Input Voltage: 90~264 Output Voltage: 8.9 Output Current: 3.0A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018089-2A Input Voltage: 90~264 Output Voltage: 8.9 Output Current: 3.0A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018089-3A Input Voltage: 90~264 Output Voltage: 8.9 Output Current: 3.0A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018009-1U Input Voltage: 90~264 Output Voltage: 9 Output Current: 2A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018009-2U Input Voltage: 90~264 Output Voltage: 9 Output Current: 2A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018009-3U Input Voltage: 90~264 Output Voltage: 9 Output Current: 2A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018009-1K Input Voltage: 90~264 Output Voltage: 9 Output Current: 2A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018009-2K Input Voltage: 90~264 Output Voltage: 9 Output Current: 2A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018009-3K Input Voltage: 90~264 Output Voltage: 9 Output Current: 2A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018009-1A Input Voltage: 90~264 Output Voltage: 9 Output Current: 2A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018009-2A Input Voltage: 90~264 Output Voltage: 9 Output Current: 2A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018009-3A Input Voltage: 90~264 Output Voltage: 9 Output Current: 2A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018119-1U Input Voltage: 90~264 Output Voltage: 11.9 Output Current: 2A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018119-2U Input Voltage: 90~264 Output Voltage: 11.9 Output Current: 2A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018119-3U Input Voltage: 90~264 Output Voltage: 11.9 Output Current: 2A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018119-1K Input Voltage: 90~264 Output Voltage: 11.9 Output Current: 2A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018119-2K Input Voltage: 90~264 Output Voltage: 11.9 Output Current: 2A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018119-3K Input Voltage: 90~264 Output Voltage: 11.9 Output Current: 2A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018119-1A Input Voltage: 90~264 Output Voltage: 11.9 Output Current: 2A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018119-2A Input Voltage: 90~264 Output Voltage: 11.9 Output Current: 2A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018119-3A Input Voltage: 90~264 Output Voltage: 11.9 Output Current: 2A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018012-1U Input Voltage: 90~264 Output Voltage: 12 Output Current: 1.5A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018012-2U Input Voltage: 90~264 Output Voltage: 12 Output Current: 1.5A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018012-3U Input Voltage: 90~264 Output Voltage: 12 Output Current: 1.5A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018012-1K Input Voltage: 90~264 Output Voltage: 12 Output Current: 1.5A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018012-2K Input Voltage: 90~264 Output Voltage: 12 Output Current: 1.5A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018012-3K Input Voltage: 90~264 Output Voltage: 12 Output Current: 1.5A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018012-1A Input Voltage: 90~264 Output Voltage: 12 Output Current: 1.5A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018012-2A Input Voltage: 90~264 Output Voltage: 12 Output Current: 1.5A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018012-3A Input Voltage: 90~264 Output Voltage: 12 Output Current: 1.5A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018179-1U Input Voltage: 90~264 Output Voltage: 17.9 Output Current: 1.5A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018179-2U Input Voltage: 90~264 Output Voltage: 17.9 Output Current: 1.5A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018179-3U Input Voltage: 90~264 Output Voltage: 17.9 Output Current: 1.5A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018179-1K Input Voltage: 90~264 Output Voltage: 17.9 Output Current: 1.5A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018179-2K Input Voltage: 90~264 Output Voltage: 17.9 Output Current: 1.5A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018179-3K Input Voltage: 90~264 Output Voltage: 17.9 Output Current: 1.5A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018179-1A Input Voltage: 90~264 Output Voltage: 17.9 Output Current: 1.5A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018179-2A Input Voltage: 90~264 Output Voltage: 17.9 Output Current: 1.5A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018179-3A Input Voltage: 90~264 Output Voltage: 17.9 Output Current: 1.5A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018018-1U Input Voltage: 90~264 Output Voltage: 18 Output Current: 1A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018018-2U Input Voltage: 90~264 Output Voltage: 18 Output Current: 1A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018018-3U Input Voltage: 90~264 Output Voltage: 18 Output Current: 1A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018018-1K Input Voltage: 90~264 Output Voltage: 18 Output Current: 1A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018018-2K Input Voltage: 90~264 Output Voltage: 18 Output Current: 1A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018018-3K Input Voltage: 90~264 Output Voltage: 18 Output Current: 1A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018018-1A Input Voltage: 90~264 Output Voltage: 18 Output Current: 1A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018018-2A Input Voltage: 90~264 Output Voltage: 18 Output Current: 1A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018018-3A Input Voltage: 90~264 Output Voltage: 18 Output Current: 1A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018239-1U Input Voltage: 90~264 Output Voltage: 23.9 Output Current: 1A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018239-2U Input Voltage: 90~264 Output Voltage: 23.9 Output Current: 1A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018239-3U Input Voltage: 90~264 Output Voltage: 23.9 Output Current: 1A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018239-1K Input Voltage: 90~264 Output Voltage: 23.9 Output Current: 1A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018239-2K Input Voltage: 90~264 Output Voltage: 23.9 Output Current: 1A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018239-3K Input Voltage: 90~264 Output Voltage: 23.9 Output Current: 1A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018239-1A Input Voltage: 90~264 Output Voltage: 23.9 Output Current: 1A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018239-2A Input Voltage: 90~264 Output Voltage: 23.9 Output Current: 1A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018239-3A Input Voltage: 90~264 Output Voltage: 23.9 Output Current: 1A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018024-1U Input Voltage: 90~264 Output Voltage: 24 Output Current: 0.75A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018024-2U Input Voltage: 90~264 Output Voltage: 24 Output Current: 0.75A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018024-3U Input Voltage: 90~264 Output Voltage: 24 Output Current: 0.75A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018024-1K Input Voltage: 90~264 Output Voltage: 24 Output Current: 0.75A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018024-2K Input Voltage: 90~264 Output Voltage: 24 Output Current: 0.75A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018024-3K Input Voltage: 90~264 Output Voltage: 24 Output Current: 0.75A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018024-1A Input Voltage: 90~264 Output Voltage: 24 Output Current: 0.75A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018024-2A Input Voltage: 90~264 Output Voltage: 24 Output Current: 0.75A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018024-3A Input Voltage: 90~264 Output Voltage: 24 Output Current: 0.75A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018349-1U Input Voltage: 90~264 Output Voltage: 34.9 Output Current: 0.75A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018349-2U Input Voltage: 90~264 Output Voltage: 34.9 Output Current: 0.75A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018349-3U Input Voltage: 90~264 Output Voltage: 34.9 Output Current: 0.75A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018349-1K Input Voltage: 90~264 Output Voltage: 34.9 Output Current: 0.75A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018349-2K Input Voltage: 90~264 Output Voltage: 34.9 Output Current: 0.75A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018349-3K Input Voltage: 90~264 Output Voltage: 34.9 Output Current: 0.75A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018349-1A Input Voltage: 90~264 Output Voltage: 34.9 Output Current: 0.75A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018349-2A Input Voltage: 90~264 Output Voltage: 34.9 Output Current: 0.75A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018349-3A Input Voltage: 90~264 Output Voltage: 34.9 Output Current: 0.75A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018035-1U Input Voltage: 90~264 Output Voltage: 35 Output Current: 0.51A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018035-2U Input Voltage: 90~264 Output Voltage: 35 Output Current: 0.51A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018035-3U Input Voltage: 90~264 Output Voltage: 35 Output Current: 0.51A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018035-1K Input Voltage: 90~264 Output Voltage: 35 Output Current: 0.51A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018035-2K Input Voltage: 90~264 Output Voltage: 35 Output Current: 0.51A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018035-3K Input Voltage: 90~264 Output Voltage: 35 Output Current: 0.51A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018035-1A Input Voltage: 90~264 Output Voltage: 35 Output Current: 0.51A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018035-2A Input Voltage: 90~264 Output Voltage: 35 Output Current: 0.51A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018035-3A Input Voltage: 90~264 Output Voltage: 35 Output Current: 0.51A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018056-1U Input Voltage: 90~264 Output Voltage: 56 Output Current: 0.51A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018056-2U Input Voltage: 90~264 Output Voltage: 56 Output Current: 0.51A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018056-3U Input Voltage: 90~264 Output Voltage: 56 Output Current: 0.51A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018056-1K Input Voltage: 90~264 Output Voltage: 56 Output Current: 0.51A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018056-2K Input Voltage: 90~264 Output Voltage: 56 Output Current: 0.51A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018056-3K Input Voltage: 90~264 Output Voltage: 56 Output Current: 0.51A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018056-1A Input Voltage: 90~264 Output Voltage: 56 Output Current: 0.51A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018056-2A Input Voltage: 90~264 Output Voltage: 56 Output Current: 0.51A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
WMBA018056-3A Input Voltage: 90~264 Output Voltage: 56 Output Current: 0.51A Output Power (W): 18 No. Outputs: S Case: Wall Mount Get a Quote
Specification Value
Input
Input Voltage (Nominal): 115/230
Input Voltage Range: 90~264
Input Frequency: 50/60Hz
Output
Output Voltage: 5, 8.9, 9, 11.9, 12, 17.9, 18, 23.9, 24, 34.9, 35, 56
Output Current: 0.51A, 0.75A, 1A, 1.5A, 2A, 3A
Output Power (Watts): 18
Short Circuit Protection: Automatic Recovery
General
Efficiency: 85%
Environmental
Operating Temperature: 0 to 40°C
Storage Temperature: -20 to 85°C
Physical
Weight: 3.05~4.03oz
Dimensions: 2.68" x 1.57" x 1.04"
Notes & safety
Notes: 1. “Y” in model number stands for package style. “Y” can either be “1” For Side Entry Case, “2” For In Line Case with USB, or “3” for In Line Case without USB.
“X” in model number stands for plug type. “X” can either be “U” for US plug, “K” for UK plug, “A” for Aus plug.
*Due to advances in technology, specifications subject to change without notice.
Safety Approvals: IEC/EN60950-1, UL/CUL60950-1, BSMI, CCC, KC, PSE, SAA
RoHS Compliance: Yes
Energy Star Compliance: Level VI
